Beschreibung:
Rated Input Current: 5A
Rated output current: 2.5mA
Ratio: 2000:1
Phase (when the rated input) : <= 30'(input current 1A, sample Resistance 100 ohm)
The linear range: 0-20A(sample Resistance 100 ohm)
Linearity <=0.2%
Accuracy class: -0.2%<=f<=+0.2%(input current 1A, sample Resistance 100 ohm)
Isolation voltage: 4500V
Operating temperature: -40 to +85 degrees
Installation: Output leads installation
Use measuring:
For precise current and power measurement.
Sealing material: Epoxy
